Arbitrary CNC Double Head Cutting Saw

1. Model No: LJB2B-CNC-550*5000/6000
2. Voltage:380V 50Hz
3. Saw Diameter: Outside 550mm Inner 30mm

Main Features

1.3-axis servo system, cutting of aluminum profiles with high speed and precision

2.Strong construction, linear rail and sliding-bearing system for precise length and angle

3.Industrial PC based on servo control system, 13” touch screen (Delta)

4.File transfer via USB

5.Central lubrication system

6.All error messages can be seen on the machine screen with the interface program which developed by Delta Software

7.High angle accuracy thanks to gearbox

8.Cooling system to cut aluminium profiles

9.The saw heads tilt automatically between ＋22.5° and －22.5° by servo motors

10.Machine can cut ultra-short and over-length profile

11.Adjustable saw cutting speed

12.Profile support conveyor is available on the machine as standard

13.Bar code printer as optional

Main Technical Parameter
